NON-CONFORMING:
Range Vue - Suggest Clubs: when enabled, these features is Non-Conforming for competitive sanctioned
rounds and will provide warning to you.
How to Setup RangeVue with Club Selection?
The SkyCaddie SX500 supports the NEW feature RangeVue with Club Selection. This feature will allow you
to program in your club distances through your SkyGolf 360 account and when enabled for use on the
SX500, will instantly show you distance remaining as well as the club suggestion. This feature can be turned
on and off for competitive sanctioned rounds.
Please follow the instructions below for setting up RangeVue with Club Selection.
1. Go to www.skygolf.com and click on the “SkyGolf 360” section at the top of the page.
2. Click on “Login” on the top of the website.
3. When the “SkyGolf 360” page opens you should see a list of option tabs at the top.
4. Click on “Edit Golf Bag”.
5. In the “Edit Bag” screen you will see a list of clubs and you can edit distances or delete clubs. (Edit to your
personal distances or Delete clubs you don’t use).
6. Once finished click on “Save”. Then, connect your SkyCaddie SX500 and sync it to update this information
to the device to use with RangeVue with Club Selection. (See screenshots on next page)

Keeping your SX500 within acceptable operating temperatures:

Similar to other high-performance electronic products, such as tablets and smartphones, the SX500 has internal temperature sensors that trigger an alert if its internal temperature exceeds recommended operating conditions that may lead to damage.

Examples of why this condition may occur would include:
• Leaving the device in a car on a hot day.
• Leaving the device in direct sunlight on a hot surface such as a golf cart seat, or the dashboard of a car for an extended period of time.


What if you receive an alert message?

If the interior temperature of the SX500 exceeds the normal operating range, the device will protect its internal components by showing an alert message.

Some functions may shut down or not operate properly until an acceptable operating temperature is resumed. After exceeding the operating ranges of 30 degrees Fahrenheit (zero Degree C) degrees to 140 degrees Fahrenheit or (60 degrees C), the power may need to be turned off and then turned back on once the operating temperature returns to normal ranges.

If this happens, Press DISMISS and move the SX500 to a cooler location, out of direct sunlight lower its internal temperature. Continued use in high temperatures or direct sunlight may damage sensitive electronics and void warranty. Do not attempt to remove battery.

The SX500 can do everything that you need through wifi connections eliminating the need to sync through USB. This means you can register, download courses, and get all updates quickly as long as you have a Wi-Fi connection.

Select “Settings” from the menu bar on the SX500 to view all of the user and system information for your SkyCaddie. This is where you will go if you needed to make any modifications to the units, tee gender, views, adjust backlight settings, battery level, time zone, etc. You can also come to this section in order to restore to factory default settings.

Please review the videos above for information on configuring your SX500 to download courses wirelessly via Wi-Fi

There is no blinking or flashing charge light on the SX500. Charging is indicated by the battery meter.

When SX500 is turned off and connected to wall charger, you will see this screen – to check if charging, simply press the power button and this screen will show.

When the SX500 it turned on, and connected to wall charger, you will see this lightning bolt in the battery meter at the top of the screen.

Locking the screen on the SX500 is as easy as pressing the green button on the upper right hand side of the device. Once that is pressed, a red/white lock symbol will appear on your screen so that you know that it is locked. To unlock, simply press the green button again.

We recommend that the SX500 is in clear view of the sky 5 minutes prior to starting your round for optimal performance.

There is no need to connect to your computer through USB. Easily connect to Wi-Fi by following the instructions below:

1. Power ON & Choose “SYNC”
2. Select “Wi-Fi Sync”
3. Choose “Set Up Wi-Fi”
4. Choose “Network” (Router)
5. Login with your Network Password and “Connect”
6. Sync Complete/ Select “CLOSE”

When searching for a golf course that’s name contains a special character you may need to use that character as part of your search.

1. Pressing and holding a key reveals alternative letters that will help you type the name correctly.
2. Type in Course Name using Keypad
3. Wait for Course Search to Complete
4. Select Course

1. From the Main Screen, Select Play Golf
2. Choose the Course to Play
3. Select Play Now
4. Choose Round Options
5. Select Auto-Hole> Options ON >OFF> Scoring ON.
6. Start Round

Currently Bluetooth is not enabled for use on the SX500 but will be in future releases we make. WIFI is the easiest and preferred method for registration, course updates and score syncing to 360.

The SX500 has a water resistance rating of IPX7. It comes in a highly water resistant, rugged design that is capable of standing up to almost anything that comes its way on the course.

All outdoor readable Liquid Crystal Displays (LCD’s) have varying types of polarizing filters that are designed to maximize the readability of the LCD display in various lighting conditions. Each manufacturer of the LCD uses the type of polarization filter that is optimized for their particular display and the normal orientation the display will be used. The SX500 LCD has filter layers designed that provide the best performance for the LCD. Major brands of sunglasses are typically polarized in order to reduce glare reflected from horizontal surfaces such as land and water. Some aviation sunglasses may not be polarized because of potential readability issues with cockpit instrumentation LCD’s. The SX500 LCD has been tested with all major brands of polarized sunglasses and is visible outdoors with those sunglasses. There may be a slight apparent darkening of the display when turned horizontally depending on the type of polarization direction of the respective sunglasses. Most sunglasses are vertically polarized, however some are polarized 45 degrees. Each will behave slightly differently with the SX500 display. Various SkyCaddie products may have different LCD’s and polarization methods optimized for the respective product LCD.

This is not a reason for a return as there is no issue with our hardware.

On the SX500, there are two types of courses that will show up in the ‘Favorites’ list:

1. Favorite courses you have downloaded from the website.

• These courses have a heart icon beside them.
• If you remove a favorite course on the website, it will be removed from the device the next time you Sync.

2. Single courses you have updated over Wi-Fi using the ‘update’ button on the course info screen.

• These courses have a Wi-Fi icon beside them.
• You don’t need to remove these courses, as they don’t take up much space and they do not count toward your 50 favorite courses.

Sadly, in today’s world, all that glitters is not gold! Beware of prices that seem too good to be true, as many times they are.

There are scam sites that may seem to have great deals on our products (and others) where their only intention is to steal your identity and wipe out your bank account.

We recommend buying only from trusted internet sites who display verified payment security certificates.

Please chat with customer support for the latest promotions on our entire line of products. Below is an article with top tips on avoiding fraud: https://www.consumer.ftc.gov/articles/0060-10-things-you-can-do-avoid-fraud

Size: 6 “x 3” x .5” inch (155.5 x 83 x 12.7 mm)
Weight: Approximately 8 ounces (250 grams)
Display: 5” LCD Touch screen, 1920x1080 resolution

Pre-loaded with over 35,000 full featured courses worldwide

Golf's most brilliant display featuring a large 5" touch screen

Patented IntelliGreen Technology, larger image and easy to use cursor movement to dial in your yardage.

Dynamic Holevue with full pinch & Zoom provides multiple views and a stunning visual experience

Integrated Targets. Simply double tap to reveal critical distances to hazards, carries & layups.

Digital Scorecard and Stat tracking

Upload scores to SkyGolf 360 via Wi-Fi

Cut the Cord!! WIFI connectivity to streamline updates & course downloads on demand. No need to connect to a computer!

Big number mode. Front, Center, Back distances in ultra large numbers

Pinpoint technology provides the ability to get distance to the pin

Engineered with a highly water-resistant and rugged design

Intelligent Automation from the parking lot to the 1st Tee

Powered by SkyGolf's ground-verified maps for unmatched accuracy

Tee box & gender selection

Longer battery life

Camera 5.0 / 13 MP

- You can now take photos on the green and save them to your SkyGolf 360 account.

The camera is accessed during round play by pressing and holding the bottom right button.

Photos taken can be uploaded to SkyGolf 360 and shared with friends.

Depending on your round time, you should be able to get up to 14 hours or 3 rounds of golf in on a full charge. The SX500 has the largest battery in the industry so it should be ready for extended playing time, that emergency 9, or even 18 more holes.

The ‘Pro Front Mark’ is a static point on the green and does not move when you change your angle of approach to the green. The pro front represents the closest point of the green when viewed from the most common angle of approach.

For example, imagine playing a hole in regulation and think of your approach shot into the green. On a par 3 you would approach the green from the tee, on a par 4 it’s from the middle of the fairway and on a par 5 it’s from a layup zone in the fairway. The Pro front mark is the first point on the front of the green which is closest to these ideal approach positions.

Why is it important?

In order to provide a tournament pin sheet to players in a professional event, the event’s tournament director will use the Pro Front as the static reference point to pace off from when setting the pins for a tournament. For example, in order to mark 9 paces on, 6 from the left, there must be a starting point.

SkyCaddie uses the same methodology as the main Tours when locating the pro front mark on a green. SkyCaddie then uses this ‘Pro Front Mark’ for its SkyPin Sheets and to assist in adding pin locations directly into products such as the SkyCaddie SX500 and SX400.

On a SkyCaddie SX400/500, Pro Front is shown this way as a red and white circle icon on the green.

When Pro Front is enabled in the settings of the SX500 or SX400, and the course you are playing has been mapped with the Pro Front Mark, an additional distance will be displayed on the IntelliGreen screen in the lower left corner marked with the red and white circle icon.

SkyCaddie will now display the dynamic front/center/back distances based on your current location and approach angle to the green as well as a distance to the static Pro Front Mark.

Because the Pro Front is a static reference point which provides the front of the green distance based on the optimal approach angle to the green, It will vary from the dynamic front distance which is based on your current location’s approach angle to the green.

NOTE: Pro Front Mark is not enabled on all SkyGolf courses

All Handheld Memberships are compatible with the SX500. To view these memberships and prices, please Click Here

SkyCaddie SX500 GPS Rangefinder
SX500 micro USB cable with extended connector
Wall charger
Quick Start Guide

*Please note that the screen on the SX500 is very durable and a screen protector is not needed for daily use.
